L 120 with gesture control

Suspended luminaire

Isometry - L 120 with gesture control

Very thin, height adjustable LED suspended luminaire for the office and home, luminaire made of aluminium, chrome-plated or anodised silver, diffusor surface made of acrylic glass, matt, indentations with integrated lens technology for directing light and suppressing glare, 100 % direct beam, version for 24 volts or external converter, the luminaire can be dimmed intuitively by a touchless gesture control system integrated on top of the housing, the luminaire is perfectly suited for a variety of lighting applications even when the suspended length is relatively short, including stainless steel suspension cables, adjustable from 300 – 1800 mm.

L 120 with gesture control
suspended luminaire
with gesture control, version for 24 V DC
max. suspended length 1800 mm

Accessories

  • External converter for cavity mounting 006-668

  • Cover for ceiling opening 005-797

Data | UGR

  • Dimensions: 1353 × 20 × 60 mm
  • Technology: LED-Technology
  • 24 V DC (without converter):
    3000 K 26 W
  • Flux: 1826 lm
  • Light distribution: 100 % direct beam
  • Protection type: IP 20

Dimensions

Dimensions

Light distribution

Light distribution
Light distribution examples
