Q Four 40°
Ceiling spot with housing made of aluminium
LED ceiling spot with flat cubic housing made of aluminium, 4 integrated Bartenbach lenses for focussing light and reducing glare, narrow beam (beam angle 40°) for accentuated illumination of surfaces and rooms, the full light performance thus appears on the illuminated area, body design formally adapting to the Nimbus families Q ONE and FRAME, operation by means of an external converter (within the scope of delivery), dimmable via DALI or via trailing/leading edge in combination with conventional wall dimmer.
The corresponding performance data can be found in the fact sheet of the luminaire.
Product specs
Q Four 40°
Ceiling spot with housing made of aluminium
Sample images
Product data
Data | UGR
- Dimensions: 128 x 128 x 36
- Technology: LED-Technology
-
230 V AC (with converter):
2700 K max. 16,4 W CRI > 90 3000 K max. 16,4 W CRI > 90 4000 K max. 16,4 W CRI > 90 - Flux: up to 960 lm
- Light distribution: 100 % direct beam
- Protection type: IP 20
X: 4H
Y: 8H
S: 1,0
H: +3,9/-2,8
reflection factors: 70/50/20
UGR transversal: < 5,4
UGR axial: < 5,4
Dimensions
Light distribution
